Technical Overview
Built-in / Free-standing
Built-in
Number of speed settings
3-stages + intensive setting
Max. air extraction
408 m³/h
Boost position air extraction
758 m³/h
Sound power at max. speed (2010/30/EC)
54 dB
Highlights
Special Features
at MAX_FOERDERLEISTUNG m3/h, it quickly ensures optimal kitchen air quality.
Total power of the motors140 W
Type of control setting and signalling devicesLED, Low-lift pushbuttons
Number of speed settings3-stages + intensive setting
Max. air extraction408 m³/h
Boost position air extraction758 m³/h
Sound power at max. speed (recirculation)60 dB
Sound power boost (recirculation)67 dB
Grease filter materialWashable aluminium
Total annual energy consumption38.5 kWh/annum
Width of the appliance898 mm
Depth of the product290 mm
Minimum distance above an electric hob430 mm
Minimum distance above a gas hob650 mm
Diameter of air outlet150 / 120 mm
Length electrical supply cord175.0 cm
Minimum width for installation524 mm
Maximum width for installation524 mm
Depth for installation290 mm
Extremely quiet - EcoSilence DriveYes
Delay Shut off modes10 min
Total power of the lamps6 W
Color temperatureNeutral (3.500 K)
Connected appliances with Home ConnectNo
