Built-in dishwashers Fully-integrated dishwasher 60 cm SMH8ZCX01E

Fully-integrated dishwasher 60 cm

1 / 12

Photo thumb Nr. 1 of the product SMH8ZCX01E

Photo thumb Nr. 2 of the product SMH8ZCX01E

Photo thumb Nr. 3 of the product SMH8ZCX01E

Photo thumb Nr. 4 of the product SMH8ZCX01E

Photo thumb Nr. 5 of the product SMH8ZCX01E

Photo thumb Nr. 6 of the product SMH8ZCX01E

Photo thumb Nr. 7 of the product SMH8ZCX01E

Photo thumb Nr. 8 of the product SMH8ZCX01E

Photo thumb Nr. 9 of the product SMH8ZCX01E

Photo thumb Nr. 10 of the product SMH8ZCX01E

Photo thumb Nr. 11 of the product SMH8ZCX01E

Photo thumb Nr. 12 of the product SMH8ZCX01E

Built-in dishwashers Fully-integrated dishwasher 60 cm SMH8ZCX01E

Fully-integrated dishwasher 60 cm

Series 8 fully-integrated dishwasher 60 cm Variable hinge for special installation situations
SMH8ZCX01E

Datasheet

Find a local Dealer

Find a local dealer in your vicinity

fully-integrated dishwasher 60 cm Variable hinge for special installation situations

Datasheet

Technical Overview

Width of the appliance

598 mm

Height of the appliance

815 mm

Energy Efficiency Class (Regulation (EU) 2017/1369)

Airborne acoustical noise emissions

39 dB(A) re 1 pW

Water protection with warranty - AquaStop

Yes

brilliantShine System

Connected appliances with Home Connect

Yes

Airborne acoustical noise emission class

Highlights

Special Features

perfect drying results with less energy usage even on difficult to dry dishes.

Individually adapts the washing and drying cycle based on your feedback.

highest flexibility and protection for your dishes, with superior sliding performance.

home appliances with smart connectivity for an easier everyday life.

extra cleaning for items in your top basket.

Specifications

Search specifications

General

Built-in / Free-standing

Built-in

Installation typology

Integrated

Removable top

Door panel options

Not possible

Variable hinge for special installation situations

Yes

Adjustable plinth

Both horizontal and vertical

Energy Efficiency Class (Regulation (EU) 2017/1369)

Airborne acoustical noise emissions

39 dB(A) re 1 pW

Airborne acoustical noise emission class

The energy consumption of the eco programme in kWH per cycle

0.747 kWh/cycle

The water consumption of the eco programme in liters per cycle

9.0 l

Programme duration

3:20 h

Energy Consumption for 100 cycles Eco Programme

75 kWh

Maximum number of place settings

List of programmes

Auto 45-65°C, Custom program, Delicate, Eco, Intensive, Short, Intelligent, Silence

Additional operational options

Remote control, Extra Dry, Intensive Zone, HygienePlus, SpeedPerfect Plus, Machine Care Programme

Water protection with warranty - AquaStop

Yes

Drying system

Zeolith, Heat exchanger

3rd Rack

VarioDrawer Pro

rackmatic normal

Yes

Tub material

Stainless steel

Included accessories 2

Vapor barrier plate

Size and weight

Dimensions of the product (HxWxD)

815 x 598 x 550 mm

Depth with open door 90 degree

1150 mm

Minimum height for installation

815 mm

Maximum height for installation

875 mm

Minimum width for installation

600 mm

Maximum width for installation

608 mm

Depth for installation

550 mm

Weight furniture front (min - max)

4.5 - 11 kg

Height of removable worktop

0 mm

Net weight

51.1 kg

Comfort

Progress indicator

Accoustic signal, water inlet

Door-opening sensor

Remaining time projection on kitchen floor

Program Status Light

Not applicable

sideLight

Yes

Emotionlight

Yes

emotionlight pro

Cleaning technology and sensoric

Precise Glass Protection

Yes

Extremely quiet - EcoSilence Drive

Yes

aquasensor

Yes

Water management system

Detergent detection

Yes

Connectivity

Connected appliances with Home Connect

Yes

Home Connect Features

Remote Monitoring and Control

Power consumption standby/network (Please check the user manual for how to switch off the WiFi module)

2.0 W

Time auto-standby/network

2.0 min

Savety

Water protection with warranty - AquaStop

Yes

Child safety devices

Manual and Documents
